Shhhhhhhhhhh!!!!!!!!!!
- Thread starter Dream Merchant
- Start date
.
.
More might be revealed ... tonight.
.
ortega
Moderator
only one way to know
ricleo
Senior Member
Is it compression issues with your image host or does the ISO 100 crops really have so much artifacts?
Details of above are:
16:9 ratio, ISO 100, Aperture priority.
Some crops:
I'm using flicke, and that compresses stuff quite a bit.
For example, 2232 x 3968 goes down to 575 x 1024 (flickr's min I assume - I am using flickr for the first time), plus what ever compression flickr imparts.
Perhaps I should put in a smaller pix? :think:
For example, 2232 x 3968 goes down to 575 x 1024 (flickr's min I assume - I am using flickr for the first time), plus what ever compression flickr imparts.
Perhaps I should put in a smaller pix? :think:
ricleo
Senior Member
icic, i'm not too familiar with using Flickr, but perhaps you can make the 100% crops smaller crops to prevent Flickr from further reducing the image size, then we will be able to take a look at the image quality without the compression.
how do you like the camera so far? feel like getting it in white haha....hope the DR is really better as what Pany has claimed
how do you like the camera so far? feel like getting it in white haha....hope the DR is really better as what Pany has claimed
Yup, white is nice.. Saw quite a few for sale on ebay.. Damn tempted to get it and sell off my LX3:dunno:
Before we give you more info, let's see if this works.
It was done using the full file size, and re-sized to 1200 (long side) x 300 dpi. The file is said to look smoother.
It was done using the full file size, and re-sized to 1200 (long side) x 300 dpi. The file is said to look smoother.
Last edited:
PRESS RELEASE
Panasonic launches DMC-LX5, successor to highly popular DMC-LX3
LX3 established premium compact digital camera category two years ago
The new LX5 sports a fully re-designed lens, CCD and image processing engine, as well as other improvements and upgrades.
The newly developed super bright F2.0 ultra wide angle 24mm LEICA DC VARIO-SUMMICRON lens minimizes distortion for stunning, true-to-life images with outstanding resolution and detail. The 24mm wide angle offers an impressive large viewing space and an optical zoom that can be extended to 3.8x (90mm) making the LX5 even more versatile.
The highly acclaimed 10.1-megapixel CCD in the LX3 has been redesigned to achieve dynamic range expansion by increasing the sensitivity and the saturation. Likewise, the Venus Engine FHD is redesigned for advanced signal processing in both photo and movie recording. The high sensitivity made possible by the new sensor and the superior signal processing by the new imaging engine elevate the picture quality in low light situations.
For movie recording, the LX5 is compatible with long time high quality HD movie recordings in AVCHD Lite, in addition to the conventional motion JPEG format. A host of creative options including Creative Movie mode, My Color mode and Film mode are available to allow for more creative expressions, not only in photography but also in videography.
The external design is also improved to pursue high operability-the thickened grip for easier hold; the newly incorporated turn-and-push jog dial for easier and faster selection of the various functions and settings. The Hot Shoe feature allows the attachment of advanced accessories such as optional Live View Finder, which helps shooting under strong daylight because of better image display visibility. The 1:1 square format setting is added in the aspect ratio option that can be selected with the switch at the side of the lens barrel.
The 3.0-inch large 460,000-dot high resolution Intelligent LCD is also redesigned by adopting High CRI (Color Rendering Index) backlight LED to greatly increase the color reproduction, offering remarkable visibility both in shooting and playing back images in any conditions from a dark night to under dazzling sunlight. Despite the high performance and the maintained size of the camera body, the battery life is extended to shoot 400 pictures (CIPA) per a single charge.
As a pocket camera for professionals and amateurs, or an advanced camera for step-up users, the LX5 promises picture quality and creativity backed up by crystallization of Panasonics state-of-the-art optical and digital technologies. With sophisticated features packed in a stylish compact design, the LX5 leads the expressive possibility of compact cameras to even higher dimensions.
1. F2.0 super bright 24mm ultra-wide-angle* high quality LEICA DC VARIO-SUMMICRON lens with minimum distortion.
The DMC-LX5 is equipped with the newly developed F2.0 24mm ultra-wide-angle LEICA DC VARIO-SUMMICRON lens wit higher resolution. The super bright, high quality lens is redesigned to extend LX3s optical zoom from 2.5x (60mm) to 3.8x (90mm), offering even more versatility for snapshots including portraits. The F2.0 lens is about twice as bright as the F2.8 lens, itself generally considered a bright lens. The result is a higher shutter speed for capturing stunningly clear, sharp, blur-free images even in lower lighting conditions. This advanced lens also makes it easier to produce beautiful photos with soft-focused background thanks to the shallow depth of field provided by the extra light.
The 24mm ultra-wide-angle lens -rare on a compact camera -gives photographers a wider range of composition possibilities. The super-high-quality LEICA DC VARIO-SUMMICRON lens minimizes distortion at the wide end so users can get stunning, true-to-life images with outstanding resolution and detail. The LX5 captures approximately 213% larger viewing space compared to what the normal 35mm camera does, and even approximately 136% larger compared to that of the 28mm wide-angle lens.
The lens unit consists of ten elements in nine groups with three aspherical lenses with five aspherical surfaces. Minimal distortion, high resolution, minimum artifacts such as chromatic aberrations, ghosting and flaring are the proof of uncompromising imaging made possible by F2.0 24mm ultra wide angle LEICA DC VARIO-SUMMICRON lens.
Incorporated Intelligent Resolution technology, the Intelligent Zoom available with the LX5 extends the zoom ratio by approximately 1.3x maintaining the picture quality even when combining a digital zoom. This means that the 3.8x optical zoom can virtually extend to 5x. Furthermore, the Extra Optical Zoom function extends zoom power to 6.7x (at 3-megapixel resolution) by using the center part of the large CCD to bring subjects even closer. In addition, the iris diaphragm allows users to adjust aperture at fine steps manually.
*35mm film camera equivalent: 24-90mm
2. Newly designed 1/1.63-inch 10.1-megapixel high sensitivity CCD with wider dynamic range.
The predecessor DMC-LX3 played a big role in ceasing the pixel count war by adopting 1/1.63-inch CCD for 10.1-megapixel recording to realize the unprecedented picture quality with a compact digital camera and even to establish a new premium compact camera category in the market. The CCD in the LX3, which was highly acclaimed by specialists worldwide was redesigned to achieve the further expansion of dynamic range by increasing the sensitivity by approximately 31% and the saturation by approximately 38%*. It is made possible by the improvement of the on-tip-lens design with larger light concentration and VCCD expansion while deepening the photo diode to manage richer signals more effectively.
The result is high resolution, noiseless pictures even in high sensitivity recording and richly reproduced gradation in highly contrasted situations. Taking advantage of the high sensitivity CCD and the brightness of the lens, the minimum illumination of LX5 is as low as 3 lux in movie recording.
Normally, to produce an image of 3:2 or 16:9 aspect ratio, a 4:3 picture is cropped so the picture does not have the maximum advantage of these extraordinary recording aspects. However, the CCD in DMC-LX5 can reproduce images shot with the lens set from 24mm to 90mm in any of three aspect ratios; 4:3, 3:2 or 16:9, so users can always capture dynamic, richly expressive shots with a wide perspective. The Multi Aspect mode allows the camera to take an image in all three aspect ratios simultaneously so that photographers can choose the one that best takes the advantage of the scene after shooting.
*Panasonic in-house comparison with DMC-LX3.
Panasonic launches DMC-LX5, successor to highly popular DMC-LX3
LX3 established premium compact digital camera category two years ago
The new LX5 sports a fully re-designed lens, CCD and image processing engine, as well as other improvements and upgrades.
The newly developed super bright F2.0 ultra wide angle 24mm LEICA DC VARIO-SUMMICRON lens minimizes distortion for stunning, true-to-life images with outstanding resolution and detail. The 24mm wide angle offers an impressive large viewing space and an optical zoom that can be extended to 3.8x (90mm) making the LX5 even more versatile.
The highly acclaimed 10.1-megapixel CCD in the LX3 has been redesigned to achieve dynamic range expansion by increasing the sensitivity and the saturation. Likewise, the Venus Engine FHD is redesigned for advanced signal processing in both photo and movie recording. The high sensitivity made possible by the new sensor and the superior signal processing by the new imaging engine elevate the picture quality in low light situations.
For movie recording, the LX5 is compatible with long time high quality HD movie recordings in AVCHD Lite, in addition to the conventional motion JPEG format. A host of creative options including Creative Movie mode, My Color mode and Film mode are available to allow for more creative expressions, not only in photography but also in videography.
The external design is also improved to pursue high operability-the thickened grip for easier hold; the newly incorporated turn-and-push jog dial for easier and faster selection of the various functions and settings. The Hot Shoe feature allows the attachment of advanced accessories such as optional Live View Finder, which helps shooting under strong daylight because of better image display visibility. The 1:1 square format setting is added in the aspect ratio option that can be selected with the switch at the side of the lens barrel.
The 3.0-inch large 460,000-dot high resolution Intelligent LCD is also redesigned by adopting High CRI (Color Rendering Index) backlight LED to greatly increase the color reproduction, offering remarkable visibility both in shooting and playing back images in any conditions from a dark night to under dazzling sunlight. Despite the high performance and the maintained size of the camera body, the battery life is extended to shoot 400 pictures (CIPA) per a single charge.
As a pocket camera for professionals and amateurs, or an advanced camera for step-up users, the LX5 promises picture quality and creativity backed up by crystallization of Panasonics state-of-the-art optical and digital technologies. With sophisticated features packed in a stylish compact design, the LX5 leads the expressive possibility of compact cameras to even higher dimensions.
1. F2.0 super bright 24mm ultra-wide-angle* high quality LEICA DC VARIO-SUMMICRON lens with minimum distortion.
The DMC-LX5 is equipped with the newly developed F2.0 24mm ultra-wide-angle LEICA DC VARIO-SUMMICRON lens wit higher resolution. The super bright, high quality lens is redesigned to extend LX3s optical zoom from 2.5x (60mm) to 3.8x (90mm), offering even more versatility for snapshots including portraits. The F2.0 lens is about twice as bright as the F2.8 lens, itself generally considered a bright lens. The result is a higher shutter speed for capturing stunningly clear, sharp, blur-free images even in lower lighting conditions. This advanced lens also makes it easier to produce beautiful photos with soft-focused background thanks to the shallow depth of field provided by the extra light.
The 24mm ultra-wide-angle lens -rare on a compact camera -gives photographers a wider range of composition possibilities. The super-high-quality LEICA DC VARIO-SUMMICRON lens minimizes distortion at the wide end so users can get stunning, true-to-life images with outstanding resolution and detail. The LX5 captures approximately 213% larger viewing space compared to what the normal 35mm camera does, and even approximately 136% larger compared to that of the 28mm wide-angle lens.
The lens unit consists of ten elements in nine groups with three aspherical lenses with five aspherical surfaces. Minimal distortion, high resolution, minimum artifacts such as chromatic aberrations, ghosting and flaring are the proof of uncompromising imaging made possible by F2.0 24mm ultra wide angle LEICA DC VARIO-SUMMICRON lens.
Incorporated Intelligent Resolution technology, the Intelligent Zoom available with the LX5 extends the zoom ratio by approximately 1.3x maintaining the picture quality even when combining a digital zoom. This means that the 3.8x optical zoom can virtually extend to 5x. Furthermore, the Extra Optical Zoom function extends zoom power to 6.7x (at 3-megapixel resolution) by using the center part of the large CCD to bring subjects even closer. In addition, the iris diaphragm allows users to adjust aperture at fine steps manually.
*35mm film camera equivalent: 24-90mm
2. Newly designed 1/1.63-inch 10.1-megapixel high sensitivity CCD with wider dynamic range.
The predecessor DMC-LX3 played a big role in ceasing the pixel count war by adopting 1/1.63-inch CCD for 10.1-megapixel recording to realize the unprecedented picture quality with a compact digital camera and even to establish a new premium compact camera category in the market. The CCD in the LX3, which was highly acclaimed by specialists worldwide was redesigned to achieve the further expansion of dynamic range by increasing the sensitivity by approximately 31% and the saturation by approximately 38%*. It is made possible by the improvement of the on-tip-lens design with larger light concentration and VCCD expansion while deepening the photo diode to manage richer signals more effectively.
The result is high resolution, noiseless pictures even in high sensitivity recording and richly reproduced gradation in highly contrasted situations. Taking advantage of the high sensitivity CCD and the brightness of the lens, the minimum illumination of LX5 is as low as 3 lux in movie recording.
Normally, to produce an image of 3:2 or 16:9 aspect ratio, a 4:3 picture is cropped so the picture does not have the maximum advantage of these extraordinary recording aspects. However, the CCD in DMC-LX5 can reproduce images shot with the lens set from 24mm to 90mm in any of three aspect ratios; 4:3, 3:2 or 16:9, so users can always capture dynamic, richly expressive shots with a wide perspective. The Multi Aspect mode allows the camera to take an image in all three aspect ratios simultaneously so that photographers can choose the one that best takes the advantage of the scene after shooting.
*Panasonic in-house comparison with DMC-LX3.
3. The new Venus Engine FHD assures high picture quality for both photo and movie
For the image processing LSI, the newly developed Venus Engine FHD gives the LX5 even higher-speed and performance. It enables the recording of beautiful photos and high-definition movies with higher quality signal processing.
The triple CPUs in this imaging engine dramatically speed up processing while achieving exceptional noise reduction performance. Energy efficiency, the Venus Engine FHD supports long-time AVCHD Lite movie recording and allows the output of images and sounds via HDMI. It also supports a super-fast response time.
The shutter release time lag is as short as approximately 0.007 seconds and the camera's quick response makes it easier to capture sudden, spur-of-the-moment photo opportunities together with the Sonic Speed AF (Auto Focus) that gain approximately 40% higher speed* and the quick startup time.
With the Intelligent Resolution technology, three areas outlines, detailed textured areas, and soft gradation areas are automatically detected. The outlined parts are enhanced to show clear edges while giving a moderate accentuation to the textured areas to make images look more finely defined. As for soft gradation, the superior noise reduction system of the Venus Engine FHD is applied to achieve smoother images. Apart from delivering consistent sharpness, the Intelligent Resolution performs precise signal processing pixel by pixel.
As a result, photo and movie images look naturally clear and crisp. The Intelligent Resolution technology also enhances the Intelligent Zoom to extend the optical zoom ratio to its approximately 1.3x equivalent and maintain the picture quality even when using the digital zoom. Details of an image in high sensitivity recording tend to be lost in the noise reduction process, but the Intelligent Resolution works to keep them.
Despite its high performance, the Venus Engine FHD is highly energy efficient, extending the battery life of the LX5 to 400 pictures (CIPA) per single charge.
*In comparison with DMC-LX3, using 1-area AF, at wide/tele-end.
4. Save memories in movie -Start enjoying videography as you enjoy photography.
In addition to Motion JPEG, the LX5 records high-definition motion pictures in AVCHD Lite, which almost doubles the recording time in HD quality compared with the conventional Motion JPEG format. The picture quality is enhanced by the newly added Intelligent Resolution technology. The LX5 also features Dolby Digital Creator to record high quality audios.
The LX5 goes beyond recording HD movies. It features a Creative Movie mode that lets users set the shutter speed and aperture manually. Changing the shutter speed brings special effects
Panasonic Corporation to movies, especially when shooting fast-moving subjects. The ability to control the aperture is convenient when there are several subjects at different distances yet all needs to stand out.
The optical zoom is also available in movie recordings. With the newly added Video Divide function, users can divide the video into two sections to shorten or delete the unwanted part directly from the camera. The Intelligent Resolution technology allows users to cut out a clear still image from a movie in the camera. The wind cut function blocks out most of the noise from background wind. The minimum illumination is as low as 3 lux, thanks to the F2.0 super bright LEICA DC VARIO-SUMMICRON lens and the high sensitivity CCD.
The popular iA (Intelligent Auto) is also available in movie recording. The POWER O.I.S. (Optical Image Stabilizer), Face Detection, and Intelligent Scene Selector all work together to make beautiful movies easily. The Intelligent Scene Selector automatically switches between Normal, Portrait, Macro, Scenery, and Low Light modes, according to the situation to optimize visual quality. The Intelligent Exposure optimizes the exposure to prevent over/under exposure from occurring.
Still or motion images recorded in AVCHD Lite on SD Memory Cards are easy to view on a Panasonic VIERA TV. Simply insert the card into the VIERA Image Viewer (SD Memory Card slot) on VIERA TV or DIGA Blu-ray Disc Player to playback content. Alternatively, you can use an optional mini HDMI cable to output the still and motion images you took from the LX5 directly to the TV for VIERA Link. You can take maximum advantage of LUMIX camera's playback functions including the slideshow in which both still and motion images are integrated in the timeline and category playback according to the scene mode used or calendar display and so on. All control is possible using only the TV's remote control.
With the bundled software, PHOTOfunSTUDIO 5.0 HD Edition, viewing and editing recorded content is a breeze. It also allows users to upload their videos to YouTube or burn them to a DVD disc for archiving.
Motion images can be recorded continuously for up to 29min 59 sec in European PAL areas
Continuous recording exceeding 2GB is not possible when recording motion JPEG. Remaining time for continuous recording is displayed on the screen.
Use a card with SD Speed Class with "Class 4" or higher when recording motion pictures in [AVCHD Lite]. Also, use a card with SD Speed
Class with "Class 6" or higher when recording motion pictures in [MOTION JPEG].
*SD Speed Class is the speed standard regarding continuous writing.
5. Enhanced operability and unlimited possibility for expression
The LX5 has been designed to deliver maximum operability based on feedback from the users of the predecessor LX3. Both models almost share the same size, but LX5 comes with a new gently formed grip that makes easier handling even while actively shooting. The Hot Shoe is also a newly added for attachment of the optional Live View Finder (DMW-LVF1). Users can also choose the External Optical Viewfinder (DMW-VF1) whenever it suits them. The newly adopted jog dial enhances the operability for quick setting change and the dedicated playback button lets the user playback the images and return to the shooting menu in split seconds. The aspect ratio can be changed directly with the aspect switch on the lens barrel - 4:3, 3:2, 16:9 and the new 1:1.
In addition to the Film mode in which users can select the texture of the photo as they choose a film, My Color mode is added to LX5. My Color mode is a special option that gives free reign to the user's creativity. Users can select the color out of 12 options including Expressive, Retro, Pure, Elegant, Monochrome, Dynamic Art, Silhouette, Pin Hole, Film Grain, High Dynamic, Dynamic B&W and Custom (the parameter of color / brightness / saturation adjustable). This makes it easier and more fun to create interesting, expressive images. The user can adjust the settings that best suit the shooting conditions and his or her expressive intent, for greater photographic control. It is available also in movie recording, giving the user a wider range of expressive possibilities to explore together with the Creative Movie mode.
6. Other features that add fun and ease-of-use to the camera.
The LX5 is equipped with a 3.0-inch, 460,000-dot Intelligent LCD with super high resolution and a wide viewing angle. The screen brightness automatically adjusts in 11 steps as the surrounding brightness level changes, ensuring good visibility at all times. The big screen reflects fine details, making it easy to check the focus before shooting. It also serves as a small photo and video viewer, allowing users to enjoy viewing both the still and motion images together. Reflection is suppressed with the AR coating and the adoption of the High CRI (Color Rendering Index) LED backlight realizes vivid, impressive color reproduction true to the memory color that you envision.
The ISO value can be set in 1/3 EV increments for finer control. The maximum setting is ISO 12800* enabling shooting in extremely dark places. The new Step Zoom option allows zoom ranges to be set to 24mm, 28mm, 35mm, 70mm or 90mm via the easy menu as you change the fixed focal length lens with D-SLR. The maximum 800mm is possible if the Intelligent Zoom and digital zoom is combined.
The LX5 has advanced functions that will satisfy experienced photographers, yet is easy enough for beginners to use comfortably if iA (intelligent Auto) mode is used. POWER O.I.S. (Optical Image Stabilizer), Face Recognition, AF Tracking, Intelligent ISO Control, Intelligent Scene Selector, and Intelligent Exposure are all available in photo recording and POWER O.I.S. Once you enter the iA mode, these functions are activated instantly and automatically, so you can shoot without the bother of adjusting settings every time conditions change.
*In 3-megapixel recording mode.
7. Rich options for expandability.
LX5 offers a wide variety of options to choose from to match every shooting situation and shooting style. Hot Shoe allows the attachment of optional tilt-shift Live View Finder of 1.04x (0.52x*) magnification, 202,000-dot, 100% field of view, which ensures comfortable monitoring even under the strong daylight.
Live View Finder: DMW-LVF1
External Optical View Finder: DMW-VF1
Wide Conversion Lens: DMW-LWA52 NEW
Conversion Lens Adaptor: DMW-LA6 NEW
MC Protector: DMW-MC52
ND Filter: DMW-LND52
PL Filter: DMW-LPL52
External Flash: DMW-FL220(GN22) / DMW-FL360(GN36) / DMW-FL500(GN50)
Genuine Leather Case
MW-CLX5 NEW
Battery Pack: DMW-BCJ13 NEW
For the image processing LSI, the newly developed Venus Engine FHD gives the LX5 even higher-speed and performance. It enables the recording of beautiful photos and high-definition movies with higher quality signal processing.
The triple CPUs in this imaging engine dramatically speed up processing while achieving exceptional noise reduction performance. Energy efficiency, the Venus Engine FHD supports long-time AVCHD Lite movie recording and allows the output of images and sounds via HDMI. It also supports a super-fast response time.
The shutter release time lag is as short as approximately 0.007 seconds and the camera's quick response makes it easier to capture sudden, spur-of-the-moment photo opportunities together with the Sonic Speed AF (Auto Focus) that gain approximately 40% higher speed* and the quick startup time.
With the Intelligent Resolution technology, three areas outlines, detailed textured areas, and soft gradation areas are automatically detected. The outlined parts are enhanced to show clear edges while giving a moderate accentuation to the textured areas to make images look more finely defined. As for soft gradation, the superior noise reduction system of the Venus Engine FHD is applied to achieve smoother images. Apart from delivering consistent sharpness, the Intelligent Resolution performs precise signal processing pixel by pixel.
As a result, photo and movie images look naturally clear and crisp. The Intelligent Resolution technology also enhances the Intelligent Zoom to extend the optical zoom ratio to its approximately 1.3x equivalent and maintain the picture quality even when using the digital zoom. Details of an image in high sensitivity recording tend to be lost in the noise reduction process, but the Intelligent Resolution works to keep them.
Despite its high performance, the Venus Engine FHD is highly energy efficient, extending the battery life of the LX5 to 400 pictures (CIPA) per single charge.
*In comparison with DMC-LX3, using 1-area AF, at wide/tele-end.
4. Save memories in movie -Start enjoying videography as you enjoy photography.
In addition to Motion JPEG, the LX5 records high-definition motion pictures in AVCHD Lite, which almost doubles the recording time in HD quality compared with the conventional Motion JPEG format. The picture quality is enhanced by the newly added Intelligent Resolution technology. The LX5 also features Dolby Digital Creator to record high quality audios.
The LX5 goes beyond recording HD movies. It features a Creative Movie mode that lets users set the shutter speed and aperture manually. Changing the shutter speed brings special effects
Panasonic Corporation to movies, especially when shooting fast-moving subjects. The ability to control the aperture is convenient when there are several subjects at different distances yet all needs to stand out.
The optical zoom is also available in movie recordings. With the newly added Video Divide function, users can divide the video into two sections to shorten or delete the unwanted part directly from the camera. The Intelligent Resolution technology allows users to cut out a clear still image from a movie in the camera. The wind cut function blocks out most of the noise from background wind. The minimum illumination is as low as 3 lux, thanks to the F2.0 super bright LEICA DC VARIO-SUMMICRON lens and the high sensitivity CCD.
The popular iA (Intelligent Auto) is also available in movie recording. The POWER O.I.S. (Optical Image Stabilizer), Face Detection, and Intelligent Scene Selector all work together to make beautiful movies easily. The Intelligent Scene Selector automatically switches between Normal, Portrait, Macro, Scenery, and Low Light modes, according to the situation to optimize visual quality. The Intelligent Exposure optimizes the exposure to prevent over/under exposure from occurring.
Still or motion images recorded in AVCHD Lite on SD Memory Cards are easy to view on a Panasonic VIERA TV. Simply insert the card into the VIERA Image Viewer (SD Memory Card slot) on VIERA TV or DIGA Blu-ray Disc Player to playback content. Alternatively, you can use an optional mini HDMI cable to output the still and motion images you took from the LX5 directly to the TV for VIERA Link. You can take maximum advantage of LUMIX camera's playback functions including the slideshow in which both still and motion images are integrated in the timeline and category playback according to the scene mode used or calendar display and so on. All control is possible using only the TV's remote control.
With the bundled software, PHOTOfunSTUDIO 5.0 HD Edition, viewing and editing recorded content is a breeze. It also allows users to upload their videos to YouTube or burn them to a DVD disc for archiving.
Motion images can be recorded continuously for up to 29min 59 sec in European PAL areas
Continuous recording exceeding 2GB is not possible when recording motion JPEG. Remaining time for continuous recording is displayed on the screen.
Use a card with SD Speed Class with "Class 4" or higher when recording motion pictures in [AVCHD Lite]. Also, use a card with SD Speed
Class with "Class 6" or higher when recording motion pictures in [MOTION JPEG].
*SD Speed Class is the speed standard regarding continuous writing.
5. Enhanced operability and unlimited possibility for expression
The LX5 has been designed to deliver maximum operability based on feedback from the users of the predecessor LX3. Both models almost share the same size, but LX5 comes with a new gently formed grip that makes easier handling even while actively shooting. The Hot Shoe is also a newly added for attachment of the optional Live View Finder (DMW-LVF1). Users can also choose the External Optical Viewfinder (DMW-VF1) whenever it suits them. The newly adopted jog dial enhances the operability for quick setting change and the dedicated playback button lets the user playback the images and return to the shooting menu in split seconds. The aspect ratio can be changed directly with the aspect switch on the lens barrel - 4:3, 3:2, 16:9 and the new 1:1.
In addition to the Film mode in which users can select the texture of the photo as they choose a film, My Color mode is added to LX5. My Color mode is a special option that gives free reign to the user's creativity. Users can select the color out of 12 options including Expressive, Retro, Pure, Elegant, Monochrome, Dynamic Art, Silhouette, Pin Hole, Film Grain, High Dynamic, Dynamic B&W and Custom (the parameter of color / brightness / saturation adjustable). This makes it easier and more fun to create interesting, expressive images. The user can adjust the settings that best suit the shooting conditions and his or her expressive intent, for greater photographic control. It is available also in movie recording, giving the user a wider range of expressive possibilities to explore together with the Creative Movie mode.
6. Other features that add fun and ease-of-use to the camera.
The LX5 is equipped with a 3.0-inch, 460,000-dot Intelligent LCD with super high resolution and a wide viewing angle. The screen brightness automatically adjusts in 11 steps as the surrounding brightness level changes, ensuring good visibility at all times. The big screen reflects fine details, making it easy to check the focus before shooting. It also serves as a small photo and video viewer, allowing users to enjoy viewing both the still and motion images together. Reflection is suppressed with the AR coating and the adoption of the High CRI (Color Rendering Index) LED backlight realizes vivid, impressive color reproduction true to the memory color that you envision.
The ISO value can be set in 1/3 EV increments for finer control. The maximum setting is ISO 12800* enabling shooting in extremely dark places. The new Step Zoom option allows zoom ranges to be set to 24mm, 28mm, 35mm, 70mm or 90mm via the easy menu as you change the fixed focal length lens with D-SLR. The maximum 800mm is possible if the Intelligent Zoom and digital zoom is combined.
The LX5 has advanced functions that will satisfy experienced photographers, yet is easy enough for beginners to use comfortably if iA (intelligent Auto) mode is used. POWER O.I.S. (Optical Image Stabilizer), Face Recognition, AF Tracking, Intelligent ISO Control, Intelligent Scene Selector, and Intelligent Exposure are all available in photo recording and POWER O.I.S. Once you enter the iA mode, these functions are activated instantly and automatically, so you can shoot without the bother of adjusting settings every time conditions change.
*In 3-megapixel recording mode.
7. Rich options for expandability.
LX5 offers a wide variety of options to choose from to match every shooting situation and shooting style. Hot Shoe allows the attachment of optional tilt-shift Live View Finder of 1.04x (0.52x*) magnification, 202,000-dot, 100% field of view, which ensures comfortable monitoring even under the strong daylight.
Live View Finder: DMW-LVF1
External Optical View Finder: DMW-VF1
Wide Conversion Lens: DMW-LWA52 NEW
Conversion Lens Adaptor: DMW-LA6 NEW
MC Protector: DMW-MC52
ND Filter: DMW-LND52
PL Filter: DMW-LPL52
External Flash: DMW-FL220(GN22) / DMW-FL360(GN36) / DMW-FL500(GN50)
Genuine Leather Case
MW-CLX5 NEW Battery Pack: DMW-BCJ13 NEW
About PHOTOfunSTUDIO 5.0 HD Edition
The PHOTOfunSTUDIO 5.0 HD edition comes bundled with LX5. With quick start-up and fast read-in of images, the PHOTOfunSTUDIO 5.0 HD Edition makes it possible to sort and organize images.
The Face Recognition function recognizes the faces in the picture and the software automatically sorts the photos by the registered faces without picking out each photo one by one when you only want pictures of a specific person.
You can also enjoy slideshows with a variety of effects and use your iTunes music library as background music.
Motion pictures can be uploaded directly to YouTube using the built-in YouTube uploader even in HD (High Definition) quality.
It also lets you create a 360-degree rotation panorama file in MOV, which is especially easy if Panorama Assist mode in the camera is used.
Leica is a registered trademark of Leica Microsystems IR GmbH.
The LEICA DC VARIO-SUMMICRON lenses are manufactured using measurement instruments and quality assurance systems that have been certified by Leica Camera AG based on the company's quality standards.
The "AVCHD" is a high definition (HD) digital video recording / playback format jointly established by Panasonic Corporation and Sony Corporation. The "AVCHD Lite" is a subset of the "AVCHD format" for HD digital video cameras with HD video recording restricted to 720P. The new "AVCHD Lite" Logo and the "AVCHD Lite" License are restricted to devices within the AVCHD Video Camera category. Digital cameras have been added to the AVCHD Video Camera category.
The "AVCHD Lite" and the "AVCHD Lite" logo are trademarks of Panasonic Corporation and Sony Corporation.
AVCHD Lite motion images recorded onto an SD Memory Card or a DVD disc cannot be played on a device that does not support the AVCHD standard.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.
YouTube is a trademark of Google Inc.
All other company and product names are trademarks of their respective corporations.
This unit is compatible with both SD/SDHC/SDXC Memory Cards. You can only use SDHC
Memory Cards on devices that are compatible with them. You cannot use SDHC Memory Cards on devices that are only compatible with SD Memory Cards. (When using an SDHC Memory Card on another device, be sure to read the operating instructions for that device.)
Some accessories are not available in some countries.
The use of recorded or printed materials that are protected by copyright for any purpose other than personal enjoyment is prohibited, as it would infringe upon the rights of the copyright holder.
Design and specifications are subject to change without notice.
The PHOTOfunSTUDIO 5.0 HD edition comes bundled with LX5. With quick start-up and fast read-in of images, the PHOTOfunSTUDIO 5.0 HD Edition makes it possible to sort and organize images.
The Face Recognition function recognizes the faces in the picture and the software automatically sorts the photos by the registered faces without picking out each photo one by one when you only want pictures of a specific person.
You can also enjoy slideshows with a variety of effects and use your iTunes music library as background music.
Motion pictures can be uploaded directly to YouTube using the built-in YouTube uploader even in HD (High Definition) quality.
It also lets you create a 360-degree rotation panorama file in MOV, which is especially easy if Panorama Assist mode in the camera is used.
Leica is a registered trademark of Leica Microsystems IR GmbH.
The LEICA DC VARIO-SUMMICRON lenses are manufactured using measurement instruments and quality assurance systems that have been certified by Leica Camera AG based on the company's quality standards.
The "AVCHD" is a high definition (HD) digital video recording / playback format jointly established by Panasonic Corporation and Sony Corporation. The "AVCHD Lite" is a subset of the "AVCHD format" for HD digital video cameras with HD video recording restricted to 720P. The new "AVCHD Lite" Logo and the "AVCHD Lite" License are restricted to devices within the AVCHD Video Camera category. Digital cameras have been added to the AVCHD Video Camera category.
The "AVCHD Lite" and the "AVCHD Lite" logo are trademarks of Panasonic Corporation and Sony Corporation.
AVCHD Lite motion images recorded onto an SD Memory Card or a DVD disc cannot be played on a device that does not support the AVCHD standard.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.
YouTube is a trademark of Google Inc.
All other company and product names are trademarks of their respective corporations.
This unit is compatible with both SD/SDHC/SDXC Memory Cards. You can only use SDHC
Memory Cards on devices that are compatible with them. You cannot use SDHC Memory Cards on devices that are only compatible with SD Memory Cards. (When using an SDHC Memory Card on another device, be sure to read the operating instructions for that device.)
Some accessories are not available in some countries.
The use of recorded or printed materials that are protected by copyright for any purpose other than personal enjoyment is prohibited, as it would infringe upon the rights of the copyright holder.
Design and specifications are subject to change without notice.
Camera Effective Pixels: 10.1 Megapixels
Sensor Size / Total Pixels / Filter: 1/1.63-inch / 11.3 Total Megapixels / Primary Color Filter
Aperture: F2.0 - 3.3 / Multistage Iris Diaphragm (F2.0 - 8 (W) / F3.3 - 8 (T))
(F2.0 - 11 (W) / F3.3 - 18 (T) in movie recording)
Optical Zoom: 3.8x
Digital Zoom: 4x
( Max. 15.1 x combined with Optical Zoom without Extra Optical Zoom)
(Max. 26.8 x combined with Extra Optical Zoom)
Focal Length: f=5.1-19.2mm (24-90mm in 35mm equiv.)
(25-95mm in 35mm equiv. in movie recording)
Lens: LEICA DC VARIO-SUMMICRON
10 elements in 9 groups
(3 Aspherical Lenses / 5 Aspherical surfaces)
Optical Image Stabilizer: Power O.I.S. (Off / Auto / Mode1 / Mode2) Photo & Movie
Conversion Lens Compatibility: Yes
Focusing Area: Normal: Wide/Tele 50 cm - infinity
Macro / Intelligent AUTO / Wide 1 cm - infinity / Tele 30cm - infinity
Focus Range Display: Yes
AF Metering: Face / AF Tracking / Multi (23pt) / 1pt (flexible / scalable)
Focus: Normal / Macro Quick AF On/Off (On in Intelligent Auto), Continuous AF On/Off AF/MF Switchable, Manual Focus(Jog Dial), One Shot AF, AF Area Select, AF Tracking
AF Assist Lamp: Yes
ISO Sensitivity: Auto / i.ISO / 80 / 100 / 200 / 400 / 800 / 1600 / 3200 / 6400* / 12800* (* by pixel mixed readout) High Sensitivity (ISO 1600-12800)
White Balance: Auto/Daylight/Cloudy/Shade/Flash/Halogen/Color Temperature/ White Set 1 / 2
White Balance Note: (Selectable at Normal Portrait, Soft Skin, Creative Portrait, Normal Sports, Creative Sports, Objects Close-up, Creative Close-up, Baby, Pet, High Sensitivity, Hi-Speed Burst, Panorama Assist, Photo Frame mode)
White Balance Adjustment: 2-axis adjustable, ±9steps each, Blue/Amber and Magenta/Green bias
Exposure: Program AE, Aperture Priority AE, Shutter Priority AE, Manual, Program Shift (Program AE Mode)
Exposure Compensation: 1/3 EV Step, ± 3 EV
Backlight Compensation: Yes (only in Intelligent AUTO mode)
Auto Bracketing: +/- 1/3 EV ~3EV step, 3 frames
Light Metering: Intelligent Multiple / Center-weighted / Spot
Face Detection: Photo & Movie
Still Image Scene Mode: Portrait, Soft Skin, Self-Portrait, Scenery, Panorama Assist, Sports, Night Portrait, Night Scenery, High Sensitivity, Food, Party, Candle Light, Baby1/2, Pet, Sunset, Hi-Speed Burst, Flash Burst, Starry Sky, Fireworks, Beach, Snow, Aerial photo
Movie Scene Mode: Portrait, Soft Skin, Self-Portrait, Scenery, Low Light, Food, Party, Candle Light, Sunset, Beach, Snow, Aerial, Pinhole, High Sensitivity
Movie Scene Mode Note: (Activated by selecting Still Picture Scene Mode then pressing movie button. Still Picture Scene Modes without corresponding Movie Scene Mode is recorded in Normal Mode)
Shutter Interval: approx. 0.5 sec
Self Timer: 2sec / 10sec
Auto Review: 1sec, 2sec, Hold, OFF
Picture Adjustment:
Contrast +2steps
Sharpness +2steps
Saturation +2steps
Noise Reduction
Image Quality: RAW, RAW+Fine, RAW+Standard, Fine, Standard
4:3 Aspect Ratio (Still Image): 3648x2736(10M) / 3072x2304(7M)/ 2560x1920(5M) / 2048x1536(3M) / 1600x1200(2M) / 640X480(0.3M)
3:2 Aspect Ratio (Still Image): 3776x2520 (9.5M) / 3168x2112 (6.5M) / 2656x1768 (4.5M) / 2112x1408 (3M) / 2048x1360 (2.5M) / 640x424 (0.3M)
16:9 Aspect Ratio (Still Image): 3968x2232 (9M) / 3328x1872 (6M) / 2784x1568 (4.5M) / 2208x1248 (2.5M) / 1920x1080 (2M) / 640x360 (0.2M)
1:1 Aspect Ratio (Still Image): 2736x2736(7.5M) / 2304x2304 (5.5M) / 1920x1920 (3.5M) / 1536x1536 (2.5M) / 480 x 480 (0.2M)
Motion Picture Recording 4:3: VGA: 640 x 480 pixels, 30fps (Motion JPEG)
QVGA: 320 x 240 pixels, 30 fps (Motion JPEG)
Motion Picture Recording 16:9: WVGA: 848 x 480 pixels, 30 fps (Motion JPEG)
Motion Picture Recording HD Movie: 1280x720 pixels,60p(CCD output is 30p)
(AVCHD Lite, SH: 17Mbps / H:13Mbps / L:9Mbps) / 30fps (Motion JPEG)
Aspect Ratio: 4:3, 3:2, 16:9, 1:1
Intelligent Exposure: Photo & Movie
Real-time Histograms: Yes
Composition Guide Lines: Yes (3 patterns)
Scene Mode Help Screen: Yes
External Flash: Yes
Viewfinder: (optional OVF/EVF)
LCD Monitor: 3.0" TFT Screen LCD Display (460K dots), AR Coating
Field of View : approx. 100% Wide Viewing Angle
AUTO Power LCD mode, Power LCD mode
High CRI (Color Rendering Index) LED backlight
Film Mode: Standard / Dynamic / Nature /Smooth / Vibrant / Nostalgic / Standard B&W / Dynamic B&W / Smooth B&W / My Film 1, 2 / Multi Film
*Works for movie recording
Playback Mode: Normal Playback, Slideshow, Category Playback, Mode Playback, Favorites Playback
OSD Language: English, Spanish
Recording Media: Built-in Memory, SD Memory Card, SDHC Memory Card, SDXC Memory Card
Interface: AV Output (NTSC), mini HDMI, USB2.0 High speed
Viera Link: Yes
Power: ID-Security Li-ion Battery Pack (3.6V, Minimum: 1250mAh) (Included) AC Adaptor (Input: 110-240V AC) (Optional)
Battery Life: 400 pictures (CIPA Standard)
Built-in-Flash: Auto, Auto/Red-eye Reduction, Forced On, Slow Sync./Red-eye Reduction, Forced Off,Flash Synchro; 1st / 2nd
0.8 - 7.2m (Wide/ISO Auto), 0.3 - 4.4m (Tele/ISO Auto)
Included Software: PHOTOfunSTUDIO 5.0 HD Edition, SILKYPIX Developer Studio 3.1 SE, QuickTime, Adobe Reader
Standard Accessories: Battery Charger, Battery Pack, AV Cable, USB Cable, Shoulder Strap, CD-ROM, Lens Ring Front, Hot Shoe Cover, Lens cap, Lens cap string
Multi-Aspect: Yes
2-Speed Zoom: No
Step Zoom: Yes
Max Auto ISO Setting: Yes
Quick Menu: Yes
Continuous Shooting Mode: Full-Resolution Image, 2.5 frames/sec Max. 5 images (Standard mode), Max. 3 img (Fine Mode)High-speed Burst Mode: approx. 6 frames/sec (img priority) approx. 10 frames/sec (speed priority) recorded in 3M for 4:3,2.5M for 3:2,2M for 16:9,2.5M for1:1)
Focus Icon Select: Yes (in Face Recognition only)
Sensor Size / Total Pixels / Filter: 1/1.63-inch / 11.3 Total Megapixels / Primary Color Filter
Aperture: F2.0 - 3.3 / Multistage Iris Diaphragm (F2.0 - 8 (W) / F3.3 - 8 (T))
(F2.0 - 11 (W) / F3.3 - 18 (T) in movie recording)
Optical Zoom: 3.8x
Digital Zoom: 4x
( Max. 15.1 x combined with Optical Zoom without Extra Optical Zoom)
(Max. 26.8 x combined with Extra Optical Zoom)
Focal Length: f=5.1-19.2mm (24-90mm in 35mm equiv.)
(25-95mm in 35mm equiv. in movie recording)
Lens: LEICA DC VARIO-SUMMICRON
10 elements in 9 groups
(3 Aspherical Lenses / 5 Aspherical surfaces)
Optical Image Stabilizer: Power O.I.S. (Off / Auto / Mode1 / Mode2) Photo & Movie
Conversion Lens Compatibility: Yes
Focusing Area: Normal: Wide/Tele 50 cm - infinity
Macro / Intelligent AUTO / Wide 1 cm - infinity / Tele 30cm - infinity
Focus Range Display: Yes
AF Metering: Face / AF Tracking / Multi (23pt) / 1pt (flexible / scalable)
Focus: Normal / Macro Quick AF On/Off (On in Intelligent Auto), Continuous AF On/Off AF/MF Switchable, Manual Focus(Jog Dial), One Shot AF, AF Area Select, AF Tracking
AF Assist Lamp: Yes
ISO Sensitivity: Auto / i.ISO / 80 / 100 / 200 / 400 / 800 / 1600 / 3200 / 6400* / 12800* (* by pixel mixed readout) High Sensitivity (ISO 1600-12800)
White Balance: Auto/Daylight/Cloudy/Shade/Flash/Halogen/Color Temperature/ White Set 1 / 2
White Balance Note: (Selectable at Normal Portrait, Soft Skin, Creative Portrait, Normal Sports, Creative Sports, Objects Close-up, Creative Close-up, Baby, Pet, High Sensitivity, Hi-Speed Burst, Panorama Assist, Photo Frame mode)
White Balance Adjustment: 2-axis adjustable, ±9steps each, Blue/Amber and Magenta/Green bias
Exposure: Program AE, Aperture Priority AE, Shutter Priority AE, Manual, Program Shift (Program AE Mode)
Exposure Compensation: 1/3 EV Step, ± 3 EV
Backlight Compensation: Yes (only in Intelligent AUTO mode)
Auto Bracketing: +/- 1/3 EV ~3EV step, 3 frames
Light Metering: Intelligent Multiple / Center-weighted / Spot
Face Detection: Photo & Movie
Still Image Scene Mode: Portrait, Soft Skin, Self-Portrait, Scenery, Panorama Assist, Sports, Night Portrait, Night Scenery, High Sensitivity, Food, Party, Candle Light, Baby1/2, Pet, Sunset, Hi-Speed Burst, Flash Burst, Starry Sky, Fireworks, Beach, Snow, Aerial photo
Movie Scene Mode: Portrait, Soft Skin, Self-Portrait, Scenery, Low Light, Food, Party, Candle Light, Sunset, Beach, Snow, Aerial, Pinhole, High Sensitivity
Movie Scene Mode Note: (Activated by selecting Still Picture Scene Mode then pressing movie button. Still Picture Scene Modes without corresponding Movie Scene Mode is recorded in Normal Mode)
Shutter Interval: approx. 0.5 sec
Self Timer: 2sec / 10sec
Auto Review: 1sec, 2sec, Hold, OFF
Picture Adjustment:
Contrast +2steps
Sharpness +2steps
Saturation +2steps
Noise Reduction
Image Quality: RAW, RAW+Fine, RAW+Standard, Fine, Standard
4:3 Aspect Ratio (Still Image): 3648x2736(10M) / 3072x2304(7M)/ 2560x1920(5M) / 2048x1536(3M) / 1600x1200(2M) / 640X480(0.3M)
3:2 Aspect Ratio (Still Image): 3776x2520 (9.5M) / 3168x2112 (6.5M) / 2656x1768 (4.5M) / 2112x1408 (3M) / 2048x1360 (2.5M) / 640x424 (0.3M)
16:9 Aspect Ratio (Still Image): 3968x2232 (9M) / 3328x1872 (6M) / 2784x1568 (4.5M) / 2208x1248 (2.5M) / 1920x1080 (2M) / 640x360 (0.2M)
1:1 Aspect Ratio (Still Image): 2736x2736(7.5M) / 2304x2304 (5.5M) / 1920x1920 (3.5M) / 1536x1536 (2.5M) / 480 x 480 (0.2M)
Motion Picture Recording 4:3: VGA: 640 x 480 pixels, 30fps (Motion JPEG)
QVGA: 320 x 240 pixels, 30 fps (Motion JPEG)
Motion Picture Recording 16:9: WVGA: 848 x 480 pixels, 30 fps (Motion JPEG)
Motion Picture Recording HD Movie: 1280x720 pixels,60p(CCD output is 30p)
(AVCHD Lite, SH: 17Mbps / H:13Mbps / L:9Mbps) / 30fps (Motion JPEG)
Aspect Ratio: 4:3, 3:2, 16:9, 1:1
Intelligent Exposure: Photo & Movie
Real-time Histograms: Yes
Composition Guide Lines: Yes (3 patterns)
Scene Mode Help Screen: Yes
External Flash: Yes
Viewfinder: (optional OVF/EVF)
LCD Monitor: 3.0" TFT Screen LCD Display (460K dots), AR Coating
Field of View : approx. 100% Wide Viewing Angle
AUTO Power LCD mode, Power LCD mode
High CRI (Color Rendering Index) LED backlight
Film Mode: Standard / Dynamic / Nature /Smooth / Vibrant / Nostalgic / Standard B&W / Dynamic B&W / Smooth B&W / My Film 1, 2 / Multi Film
*Works for movie recording
Playback Mode: Normal Playback, Slideshow, Category Playback, Mode Playback, Favorites Playback
OSD Language: English, Spanish
Recording Media: Built-in Memory, SD Memory Card, SDHC Memory Card, SDXC Memory Card
Interface: AV Output (NTSC), mini HDMI, USB2.0 High speed
Viera Link: Yes
Power: ID-Security Li-ion Battery Pack (3.6V, Minimum: 1250mAh) (Included) AC Adaptor (Input: 110-240V AC) (Optional)
Battery Life: 400 pictures (CIPA Standard)
Built-in-Flash: Auto, Auto/Red-eye Reduction, Forced On, Slow Sync./Red-eye Reduction, Forced Off,Flash Synchro; 1st / 2nd
0.8 - 7.2m (Wide/ISO Auto), 0.3 - 4.4m (Tele/ISO Auto)
Included Software: PHOTOfunSTUDIO 5.0 HD Edition, SILKYPIX Developer Studio 3.1 SE, QuickTime, Adobe Reader
Standard Accessories: Battery Charger, Battery Pack, AV Cable, USB Cable, Shoulder Strap, CD-ROM, Lens Ring Front, Hot Shoe Cover, Lens cap, Lens cap string
Multi-Aspect: Yes
2-Speed Zoom: No
Step Zoom: Yes
Max Auto ISO Setting: Yes
Quick Menu: Yes
Continuous Shooting Mode: Full-Resolution Image, 2.5 frames/sec Max. 5 images (Standard mode), Max. 3 img (Fine Mode)High-speed Burst Mode: approx. 6 frames/sec (img priority) approx. 10 frames/sec (speed priority) recorded in 3M for 4:3,2.5M for 3:2,2M for 16:9,2.5M for1:1)
Focus Icon Select: Yes (in Face Recognition only)
Optical Zoom in Motion Picture: Yes
Macro Zoom: No
Orientation Detector: Yes
Playback Motion Picture: Yes ( AVC HD Lite / Motion JPEG)
Slideshow Mode: All / Still Images Only / Motion Picture Only / Category / Favorites BGM Effect (Natural / Slow / Swing / Urban / OFF)
Show Histogram: Yes
Show Highlights: Yes
Delete Image: Single / Multi / All / All except Favorites
Cut Animation: Yes
PictBridge Support: Single / Multi / All / Favorites / DPOF
AVCHD / AVCHD Lite REC: NTSC
One-Touch Movie Button: Yes
Movie REC Guide: Yes
Wind-Cut in Motion Picture: Yes
Flash Burst Continuous Shooting Mode: Max. 5 images (Standard mode)
Continuous recordable time (Motion images):
AVCHD or AVCHD Lite with picture quality set to [FSH or SH] approx.140 min
MOTION JPEG with picture quality set to [HD] approx. 140 min
Actual recordable time (Motion images):
AVCHD or AVCHD Lite with picture quality set to [FSH or SH] approx.70 min
MOTION JPEG with picture quality set to [HD] approx. 70 min
My Color Mode:
Expressive /Retro / Pure / Elegant / Monochrome / High Dynamic / Dynamic Art / Dynamic B&W / Silhouette / Pinhole / Film Grain / Custom / Happy (only in iA mode)
*For movie recording
Intelligent ISO Control: Photo
Face Recognition: Photo
Intelligent Scene Selector: Photo (Portrait, Scenery, Night Portrait, Night Scenery, Sunset, Macro) & Movie (Portrait, Scenery, Low Light, Macro)
File Format: Still Image: JPEG(DCF/Exif2.3)
Image with Audio: JPEG (DCF / Exif2.3) + QuickTime
Motion picture: AVCHD Lite, QuickTime Motion JPEG
Mode Dial / Mode Button: Intelligent AUTO, P(Program) mode, A(Aperture Priority) mode, S(Shutter Priority) mode, M(Manual) mode, Creative Movie mode, My Color mode, Scene mode, Custom 1, 2
Copy / Title Edit / Text Stamp: Yes / Yes / Yes
Dimensions (W x H x D): 4.32 x 2.58 x 1.69 in / excl. protrusions: 1.00 in
Weight(lbs):
Approx. .61lb with Battery and SD Memory Card
Approx. .51lb without Battery and SD Memory Card
Extra Optical Zoom (EZ): 4.5x (4:3 / 7M), 5.4x (4:3 / 5M), 6.7x (4:3 / under 3M)
Shutter Speed:
Still: 60 - 1/4000 sec
Movie Mode : 1/30 - 1/20,000 sec (1/8 - 1/20,000 sec on MF operation on Creative Movie mode)
Starry Sky Mode : 15, 30, 60sec.
Digital Red Eye Correction (Red-Eye Removal): Photo
Mode Switch: [Playback] button
Easy Zoom / Zoom Resume: No / Yes
Thumbnails / Zoomed Playback: 12,30-thumbnails / Max 16x
Calendar Display / Dual-Image Playback: Yes / No
Set Favorites / Rotate Image: Yes / No
DPOF Print Setting / Set Protection: Yes / Yes
Resize / Trim / Aspect Conv. / Leveling: Yes / Yes / No / Yes
Travel Date / World Time: Yes / Yes
Built-in-Memory: Approx. 40MB
Microphone / Speaker: Mono / Yes
Touch Panel: No
Intelligent Zoom: 5.0x
AF Tracking: Photo
Intelligent Resolution Technology: Photo & Movie
Video Divide: Yes
Face Recognition Edit: Yes
HDMI output: Video: Auto / 1080i / 720p / 480p
Audio: Mono
Macro Zoom: No
Orientation Detector: Yes
Playback Motion Picture: Yes ( AVC HD Lite / Motion JPEG)
Slideshow Mode: All / Still Images Only / Motion Picture Only / Category / Favorites BGM Effect (Natural / Slow / Swing / Urban / OFF)
Show Histogram: Yes
Show Highlights: Yes
Delete Image: Single / Multi / All / All except Favorites
Cut Animation: Yes
PictBridge Support: Single / Multi / All / Favorites / DPOF
AVCHD / AVCHD Lite REC: NTSC
One-Touch Movie Button: Yes
Movie REC Guide: Yes
Wind-Cut in Motion Picture: Yes
Flash Burst Continuous Shooting Mode: Max. 5 images (Standard mode)
Continuous recordable time (Motion images):
AVCHD or AVCHD Lite with picture quality set to [FSH or SH] approx.140 min
MOTION JPEG with picture quality set to [HD] approx. 140 min
Actual recordable time (Motion images):
AVCHD or AVCHD Lite with picture quality set to [FSH or SH] approx.70 min
MOTION JPEG with picture quality set to [HD] approx. 70 min
My Color Mode:
Expressive /Retro / Pure / Elegant / Monochrome / High Dynamic / Dynamic Art / Dynamic B&W / Silhouette / Pinhole / Film Grain / Custom / Happy (only in iA mode)
*For movie recording
Intelligent ISO Control: Photo
Face Recognition: Photo
Intelligent Scene Selector: Photo (Portrait, Scenery, Night Portrait, Night Scenery, Sunset, Macro) & Movie (Portrait, Scenery, Low Light, Macro)
File Format: Still Image: JPEG(DCF/Exif2.3)
Image with Audio: JPEG (DCF / Exif2.3) + QuickTime
Motion picture: AVCHD Lite, QuickTime Motion JPEG
Mode Dial / Mode Button: Intelligent AUTO, P(Program) mode, A(Aperture Priority) mode, S(Shutter Priority) mode, M(Manual) mode, Creative Movie mode, My Color mode, Scene mode, Custom 1, 2
Copy / Title Edit / Text Stamp: Yes / Yes / Yes
Dimensions (W x H x D): 4.32 x 2.58 x 1.69 in / excl. protrusions: 1.00 in
Weight(lbs):
Approx. .61lb with Battery and SD Memory Card
Approx. .51lb without Battery and SD Memory Card
Extra Optical Zoom (EZ): 4.5x (4:3 / 7M), 5.4x (4:3 / 5M), 6.7x (4:3 / under 3M)
Shutter Speed:
Still: 60 - 1/4000 sec
Movie Mode : 1/30 - 1/20,000 sec (1/8 - 1/20,000 sec on MF operation on Creative Movie mode)
Starry Sky Mode : 15, 30, 60sec.
Digital Red Eye Correction (Red-Eye Removal): Photo
Mode Switch: [Playback] button
Easy Zoom / Zoom Resume: No / Yes
Thumbnails / Zoomed Playback: 12,30-thumbnails / Max 16x
Calendar Display / Dual-Image Playback: Yes / No
Set Favorites / Rotate Image: Yes / No
DPOF Print Setting / Set Protection: Yes / Yes
Resize / Trim / Aspect Conv. / Leveling: Yes / Yes / No / Yes
Travel Date / World Time: Yes / Yes
Built-in-Memory: Approx. 40MB
Microphone / Speaker: Mono / Yes
Touch Panel: No
Intelligent Zoom: 5.0x
AF Tracking: Photo
Intelligent Resolution Technology: Photo & Movie
Video Divide: Yes
Face Recognition Edit: Yes
HDMI output: Video: Auto / 1080i / 720p / 480p
Audio: Mono
peterpan1975
Senior Member
bro, So many info here ... you rip it out from the user manual ??? lol
ricleo
Senior Member
a little curious about the minimum aperture size we can go to on the LX5 as listed in the specs above.
why is it that the camera can reach F11/F18 in movie recording mode, but in image capture mode, only up till F8?
Aperture: F2.0 - 3.3 / Multistage Iris Diaphragm (F2.0 - 8 (W) / F3.3 - 8 (T))
(F2.0 - 11 (W) / F3.3 - 18 (T) in movie recording)
why is it that the camera can reach F11/F18 in movie recording mode, but in image capture mode, only up till F8?
Aperture: F2.0 - 3.3 / Multistage Iris Diaphragm (F2.0 - 8 (W) / F3.3 - 8 (T))
(F2.0 - 11 (W) / F3.3 - 18 (T) in movie recording)
ortega
Moderator
in the meantime you could have a look at this
http://www.clubsnap.com/forums/showthread.php?t=753888
http://www.clubsnap.com/forums/showthread.php?t=753888
